Product Summary
The AD627ARZ is an integrated, micropower instrumentation amplifier that delivers rail-to-rail output swing on single and dual (+2.2 V to ±18 V) supplies. The device provides excellent ac and dc specifications while operating at only 85 μA maximum. The AD627ARZ offers superior flexibility by allowing the user to set the gain of the device with a single external resistor while con-forming to the 8-lead industry-standard pinout configuration. With no external resistor, the AD627ARZ is configured for a gain of 5. With an external resistor, it can be set to a gain of up to 1000. Applications include: (1)4 to 20 mA loop-powered applications; (2)Low power medical instrumentation—ECG, EEG; (3)Transducer interfacing; (4)Thermocouple amplifiers; (5)Industrial process controls; (6)Low power data acquisition; (7)Portable battery-powered instruments.
Parametrics
AD627ARZ absolute maximum ratings: (1)Supply Voltage: ±18 V; (2)Internal Power Dissipation1 PDIP (N-8): 1.3 W; SOIC_N (R-8): 0.8 W; (3)-IN, +IN: -VS - 20 V to +VS + 20 V; (4)Common-Mode Input Voltage: -VS - 20 V to +VS + 20 V; (5)Differential Input Voltage (+IN - (-IN)): +VS - (-VS); (6)Output Short-Circuit Duration: Indefinite; (7)Storage Temperature Range (N, R): -65℃ to +125℃; (8)Operating Temperature Range: -40℃ to +85℃; (9)Lead Temperature (Soldering, 10 sec): 300℃.
Features
AD627ARZ features: (1)Micropower, 85 μA maximum supply current; (2)Wide power supply range (+2.2 V to ±18 V); (3)Easy to use: Gain set with one external resistor; Gain range 5 (no resistor) to 1000; (4)Higher performance than discrete designs; (5)Rail-to-rail output swing; (6)High accuracy dc performance.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 AD627ARZ |
|
IC AMP INST R-R 25MA 8SOIC |
Data Sheet |
|
|
||||||||||||||||||
|
AD627ARZ-R7 |
|
IC AMP INST R-R 25MA 8SOIC |
Data Sheet |
|
|
||||||||||||||||||
|
AD627ARZ-RL |
|
IC AMP INST R-R 25MA 8SOIC |
Data Sheet |
|
|
||||||||||||||||||
