AT24C64D-SSHM-T

EEPROM, 64K-Bit, 8-Pin SOIC, 2-Wire Serial, Electrically Erasable and Programmable, Read-only Memory

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.40 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.30~0.40

PartNumber:: AT24C64D-SSHM-T

Brand:: ATMEL Corporation - ATMEL | Pack: SOIC | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. CandyLu's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-08-07

From Other Seller

Part Number:AT24C64D-SSHM-T
US $0.30 - 0.40
CM2030-A0TR

US $0.92 - 2.50 / Piece
(0) Remove
HEF4051BT

US $0.15 - 1.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The Atmel AT24C64D-SSHM-T provides 32,768-/65,536-bits of serial electrically erasable and programmable read only memory (EEPROM) organized as 4096/8192 words of 8-bits each. The AT24C64D-SSHM-T’s cascadable feature allows up to eight devices to share a common 2-wire bus. The AT24C64D-SSHM-T is optimized for use in many industrial and commercial applications where low power and low voltage operation are essential.

Parametrics

AT24C64D-SSHM-T absolute maximum ratings: (1)Operating Temperature: -55 to +125℃; (2)Storage Temperature: -65 to +150℃; (3)Voltage on Any Pin with Respect to Ground: -1.0 to +7.0V; (4)Maximum Operating Voltage: 6.25V; (5)DC Output Current: 5.0mA.

Features

AT24C64D-SSHM-T features: (1)Low-voltage and Standard-voltage Operation; (2)Internally Organized 4096 x 8, 8192 x 8; (3)2-Wire Serial Interface; (4)Schmitt Trigger, Filtered Inputs for Noise Suppression; (5)Bi-directional Data Transfer Protocol; (6)1MHz (5.0V) and 400KHz (1.8V Compatibility); (7)Write Protect Pin for Hardware Data Protection; (8)32-Byte Page Write Mode (Partial Page Writes Allowed); (9)Self-Timed Write Cycle (5ms max); (10)High Reliability; (11)Lead-free/Halogen-free Devices; (12)8-lead JEDEC SOIC, 8-lead TSSOP, 8-lead UDFN, 8-lead XDFN, 5-lead SOT23 and 8-ball VFBGA; (13)Die Sales: Wafer Form, Waffle Pack and Bumped Wafers.
