Product Summary

The ADUM1201CRZ-RL7 is a dual-channel digital isolator based on Analog Devices’ iCoupler technology. Combining high speed CMOS and monolithic transformer technology, the ADUM1201CRZ-RL7 provide outstanding performance characteristics superior to alternatives such as optocoupler devices. The applications of the ADUM1201CRZ-RL7 include Size-critical multichannel isolation, SPI interface/data converter isolation, RS-232/RS-422/RS-485 transceiver isolation and Digital field bus isolation.

Parametrics

ADUM1201CRZ-RL7 absolute maximum ratings: (1)Storage Temperature, TST: -55 to 150℃; (2)Ambient Operating Temperature, TA: -40 to 105℃; (3)Supply Voltages, VDD1, VDD2: -0.5 to 7.0 V; (4)Input Voltage, VIA, VIB: -0.5 to VDDI + 0.5 V; (5)Output Voltage, VOA, VOB: -0.5 to VDDO + 0.5 V; (6)Average Output Current, per Pin3, IO: -35 to 35 mA; (7)Common-Mode Transients: -100 to +100 kV/μs.

Features

ADUM1201CRZ-RL7 features: (1)Narrow body SOIC 8-lead package; (2)Low power operation; (3)Bidirectional communication; (4)3 V/5 V level translation; (5)High temperature operation: 105℃; (6)High data rate: dc to 25 Mbps (NRZ); (7)Precise timing characteristics; (8)High common-mode transient immunity: > 25 kV/μs; (9)Safety and regulatory approvals.

Diagrams

ADUM1201CRZ-RL7 functional block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
ADUM1201CRZ-RL7
ADUM1201CRZ-RL7

IC ISOLATOR DIGITAL DUAL 8-SOIC
Data Sheet
0-1: $3.79
1-10: $3.40
10-25: $3.06
25-100: $2.78
100-250: $2.52
250-500: $2.25
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
ADuM1100
ADuM1100
Other

Data Sheet
Negotiable
ADUM1100AR
ADUM1100AR

IC DIGITAL ISOLATOR 1CH 8-SOIC
Data Sheet
0-98: $2.28
ADUM1100AR-RL7
ADUM1100AR-RL7

IC DIGITAL ISOL/COUPLER 8SOIC
Data Sheet
0-1: $2.92
1-10: $2.62
10-25: $2.36
25-100: $2.14
100-250: $1.94
250-500: $1.74
ADUM1100ARZ
ADUM1100ARZ

IC DIGITAL ISOLATOR 1CH 8-SOIC
Data Sheet
0-1: $2.44
1-10: $2.17
10-100: $1.78
100-250: $1.61
250-500: $1.44
500-1000: $1.22
1000-2500: $1.16
ADUM1100ARZ-RL7
ADUM1100ARZ-RL7

IC DIGITAL ISOL/COUPLER 8-SOIC
Data Sheet
0-1: $2.50
1-10: $2.24
10-25: $2.02
25-100: $1.83
100-250: $1.66
250-500: $1.49
ADUM1100BR
ADUM1100BR

IC DIGITAL ISOL/COUPLER 8SOIC
Data Sheet
0-98: $2.60
