Product Summary

The TLK2201BRCPR performs the data serialization, deserialization, and clock extraction functions for a physical layer interface device. The transceiver of TLK2201BRCPR operates at 1.25 Gbps (typical), providing up to 1 Gbps of data bandwidth over a copper or optical media interface.

Parametrics

TLK2201BRCPR absolute maximum ratings: (1)Supply voltage, VDD: –0.3V to 3V; (2)Input voltage, VI, (TTL): –0.5V to 4V; (3)DC input voltage (I/O ): –0.3V to 3V; (4)Voltage range at any terminal: –0.3 to VDD+0.3V; (5)Storage temperature, Tstg: –65℃ to 150℃; (6)Electrostatic discharge: HBM:2 kV, CDM: 1 kV; (7)Characterized free-air operating temperature range: 0℃ to 70℃.

Features

TLK2201BRCPR features: (1)1 to 1.6 Gigabits Per Second (Gbps) Serializer/Deserializer; (2)1.2 to 1.6 Gigabits Per Second (Gbps) Serializer/Deserializer (TLK2201I); (3)Low Power Consumption <200 mW at 1.25 Gbps; (4)LVPECL Compatible Differential I/O on High Speed Interface; (5)Single Monolithic PLL Design; (6)Support For 10 Bit Interface or Reduced Interface 5 Bit DDR (Double Data Rate) Clocking; (7)Receiver Differential Input Thresholds 200 mV Minimum; (8)Industrial Temperature Range From –40℃ to 85℃ (TLK2201I); (9)IEEE 802.3 Gigabit Ethernet Compliant; (10)Advanced 0.25 μm CMOS Technology; (11)No External Filter Capacitors Required; (12)Comprehensive Suite of Built-In Testability; (13)IEEE 1149.1 JTAG Support; (14)2.5-V Supply Voltage for Lowest Power Operation; (15)3.3-V Tolerant on LVTTL Inputs; (16)Hot Plug Protection; (17)64-Pin VQFP With Thermally Enhanced Package.

Diagrams

TLK2201BRCPR block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
TLK2201BRCPR
TLK2201BRCPR

Texas Instruments

Ethernet ICs 1.0 to 1.6 Gb Ethernet Transceiver

Data Sheet

0-691: $3.91
691-1000: $3.59
1000-2000: $3.46
TLK2201BRCPRG4
TLK2201BRCPRG4

Texas Instruments

Ethernet ICs 1.0 to 1.6 Gb Ethernet Transceiver

Data Sheet

0-691: $3.91
691-1000: $3.59
1000-2000: $3.46
