Product Summary

The AD629ARZ-RL is a difference amplifier with a very high input, common-mode voltage range. It is a precision device that allows the user to accurately measure differential signals in the presence of high common-mode voltages up to ±270 V. The AD629ARZ-RL can replace costly isolation amplifiers in applications that do not require galvanic isolation. The device operates over a ±270 V common-mode voltage range and has inputs that are protected from common-mode or differential mode transients up to ±500 V. The applications of the AD629ARZ-RL include: High voltage current sensing, Battery cell voltage monitors, Power supply current monitors, Motor controls, Isolation.

Parametrics

AD629ARZ-RL absolute maximum ratings: (1)Supply Voltage, VS: ±18 V; (2)Input Voltage Range, Continuous: ±300 V; (3)Common-Mode and Differential, 10 sec: ±500 V; (4)Output Short-Circuit Duration: Indefinite; (5)Pin 1 and Pin 5: –VS . 0.3 V to +VS + 0.3 V; (6)Maximum Junction Temperature: 150℃; (7)Operating Temperature Range: -55℃ to +125℃; (8)Storage Temperature Range: -65℃ to +150℃; (9)Lead Temperature (Soldering 60 sec): 300℃.

Features

AD629ARZ-RL features: (1)Improved replacement for: INA117P and INA117KU; (2)±270 V common-mode voltage range; (3)Input protection to ±500 V common mode; ±500 V differential mode; (4)Wide power supply range (±2.5 V to ±18 V); (5)±10 V output swing on ±12 V supply; (6)1 mA maximum power supply current.

Diagrams

AD629ARZ-RL block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AD629ARZ-RL
AD629ARZ-RL

IC AMP DIFF 25MA LDRIFT 8SOIC
Data Sheet
0-2500: $2.15
AD629ARZ-RL7
AD629ARZ-RL7
Other

Data Sheet
Negotiable
