JS28F320J3F75A

Embedded Flash Memory, TSOP, –2.0 to +5.6 V, high density, low cost

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.90~3.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $2.90~3.20

PartNumber:: JS28F320J3F75A

Brand:: Numonyx B.V - Numonyx | Pack: TSOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. CandyLu's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-08-03

From Other Seller

Part Number:JS28F320J3F75A
US $2.90 - 3.20
CM2030-A0TR

US $0.92 - 2.50 / Piece
(0) Remove
SIL9030CTU

US $2.50 - 5.10 / Piece
(0) Remove
Quantity:

piece

Product Summary

The JS28F320J3F75A Numonyx Embedded Flash Memory J3 Version D (J3 v. D) provides improved mainstream performance with enhanced security features, taking advantage of the high quality and reliability of the NOR-based Intel* 0.13 μm ETOX VIII process technology. Offered in 128-Mbit (16-Mbyte), 64-Mbit, and 32-Mbit densities, the JS28F320J3F75A brings reliable, low-voltage capability (3 V read, program, and erase) with high speed, low-power operation. It takes advantage of the proven manufacturing experience and is ideal for code and data applications where high density and low cost are required.

Parametrics

JS28F320J3F75A absolute maximum ratings: (1)Temperature under Bias Expanded (TA, Ambient): –40 to +85 ℃ ; (2)Storage Temperature: –65 to +125 ℃; (3)VCC Voltage: –2.0 to +5.6 V; (4)VCCQ: –2.0 to +5.6 V; (5)Voltage on any input/output signal (except VCC, VCCQ): –2.0 to VCCQ (max) + 2.0 V; (6)ISH Output Short Circuit Current: 100 mA.

Features

JS28F320J3F75A features: (1)Architecture: High-density symmetrical 128-Kbyte blocks, 256 Mbit (256 blocks), 128 Mbit (128 blocks), 64 Mbit (64 blocks), 32 Mbit (32 blocks); (2)Performance: 75 ns Initial Access Speed (128/64/32-Mbit densities), 95 ns Initial Access Speed (256 Mbit only), 25 ns 8-word and 4-word Asynchronous page-mode reads, 32-Byte Write buffer, 4 μs per Byte Effective programming time; (3)System Voltage and Power: VCC = 2.7 V to 3.6 V, VCCQ = 2.7 V to 3.6 V.
