Product Summary

The ADG749BKSZ-REEL7 is a monolithic CMOS SPDT switch. This switch is designed on a submicron process that provides low power dissipation yet gives high switching speed, low on resistance and low leakage currents. The ADG749BKSZ-REEL7 can operate from a single supply range of 1.8 V to 5.5 V, making it ideal for use in battery-powered instruments and with the new generation of DACs and ADCs from Analog Devices. Each switch of the ADG749BKSZ-REEL7 conducts equally well in both directions when on. The device exhibits break-before-make switching action. Applications include: Battery-Powered Systems, Communication Systems, Sample Hold Systems, Audio Signal Routing, Video Switching, Mechanical Reed Relay Replacement.

Parametrics

ADG749BKSZ-REEL7 absolute maximum ratings: (1)VDD to GND: –0.3 V to +7 V; (2)Analog, Digital Inputs: –0.3 V to VDD + 0.3 V or 30mA, Whichever Occurs First; (3)Peak Current, S or D: 100 mA(Pulsed at 1 ms, 10% Duty Cycle max); (4)Continuous Current, S or D: 30 mA; (5)Operating Temperature Range Industrial (B Version): –40℃ to +85℃; (6)Storage Temperature Range: –65℃ to +150℃; (7)Junction Temperature: 150℃; (8)SC70 Package, Power Dissipation: 315 mW; θJA Thermal Impedance: 332℃/W; θJC Thermal Impedance: 120℃/W; (9)Lead Temperature, Soldering Vapor Phase (60 sec): 215℃; Infrared (15 sec): 220℃; (10)ESD: 1.5 kV.

Features

ADG749BKSZ-REEL7 features: (1)1.8 V to 5.5 V Single Supply; (2)5Ω (Max) On Resistance; (3)0.75Ω (Typ) On-Resistance Flatness; (4)–3 dB Bandwidth >200 MHz; (5)Rail-to-Rail Operation; (6)6-Lead SC70 Package; (7)Fast Switching Times tON 20 ns; tOFF 6 ns; (8)Typical Power Consumption (<0.01 μW); (9)TTL/CMOS-Compatible.
