AD8091ARZ-REEL7

amplifier, SOIC, 12.6 V, low cost, voltage feedback, high speed, Low distortion

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.85~0.95 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.85~0.95

PartNumber:: AD8091ARZ-REEL7

Brand:: Analog Devices - ADI | Pack: SOIC | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. CandyLu's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-08-03

From Other Seller

Part Number:AD8091ARZ-REEL7
US $0.85 - 0.95
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
HEF4051BT

US $0.15 - 1.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AD8091ARZ-REEL7 is a low cost, voltage feedback, high speed amplifier, which is designed to operate on +3 V, +5 V, or ±5 V supplies. It has true single-supply capability, with an input voltage range extending 200 mV below the negative rail and within 1 V of the positive rail. The applications of the AD8091ARZ-REEL7 include Coaxial cable drivers, Active filters, Video switchers, Professional cameras, CCD imaging systems, CDs/DVDs.

Parametrics

AD8091ARZ-REEL7 absolute maximum ratings: (1)Supply Voltage: 12.6 V; (2)Common-Mode Input Voltage: ±VS; (3)Differential Input Voltage: ±2.5 V; (4)Storage Temperature Range: -65℃ to +125℃; (5)Operating Temperature Range: -40℃ to +85℃; (6)Lead Temperature Range (Soldering 10 sec): 300℃.

Features

AD8091ARZ-REEL7 features: (1)Low cost single (AD8091), dual (AD8092) amplifiers; (2)Fully specified at +3 V, +5 V, and ±5 V supplies; (3)Single-supply operation Output swings to within 25 mV of either rail; (4)High-speed and fast settling on 5 V: 110 MHz, .3 dB bandwidth (G = +1), 145 V/μs slew rate, 50 ns settling time to 0.1%; (5)Good video specifications (G = +2): Gain flatness of 0.1 dB to 20 MHz; RL = 150 Ω, 0.03% differential gain error; RL = 1 kΩ, 0.03° differential phase error; RL = 1 kΩ; (6)Low distortion: -80 dBc total harmonic @ 1 MHz; RL = 100 Ω; (7)Outstanding load drive capability: Drives 45 mA, 0.5 V from supply rails, Drives 50 pF capacitive load (G = +1); (8)Low power of 4.4 mA/Amplifier.
